Customized Automatic Magnet Wire Winding Machine for Metal & Metallurgy Coiling Process

Customized Automatic Magnet Wire Winding Machine for Metal & Metallurgy Coiling Process

customized automatic winding machine

magnet wire coiling machine

metal metallurgy winding machine

起源の場所:

中国

ブランド名:

YUYANG

証明:

CE

モデル番号:

YYH-20AB

連絡 ください
引用を要求しなさい
製品詳細
最大変動力:
20kw
仕事力:
340V-430V
最大入力電流:
30a
出力電力:
20kw
変動周波数:
50-250KHZ
冷却水の流量:
0.2Mpa、6L/min
水温保護ポイント:
40c
製品サイズ:
560×260×560mm
純重量 :
28kg
ハイライト:

customized automatic winding machine

,

magnet wire coiling machine

,

metal metallurgy winding machine

支払いと送料の条件
最小注文数量
1セット
価格
$2000
パッケージの詳細
ベニヤ箱
受渡し時間
5~10営業日
支払条件
T/T、L/C、ウェスタンユニオン
供給の能力
月200セット
製品説明
Customized Automatic Magnet Wire Winding Machine
This advanced induction heating machine is specifically designed for metal and metallurgy coiling processes, offering efficient, secure, and environmentally friendly operation.
Key Characteristics
  • IGBT inverting device with automatic frequency tracking
  • High-frequency operation with rapid heating and 20-30% lower power consumption compared to electronic tube induction heating
  • Secure voltage operation with enhanced safety features
  • Manual and automatic regulation with comprehensive protection against over voltage, over current, water shortage, phase failure, and overheating
  • No open-fire, noise, or pollution - environmentally friendly and fire-safe
  • Recommended for brazing, welding, forging, hot cooperation, melting, quenching, and annealing processes
Advanced Features
Utilizing the most advanced electric components and unique high-new techniques, this high-frequency induction heating machine provides rapid, localized metal heating. It can penetrate non-metal materials to heat metals until fusion without direct contact, solving technical problems safely and efficiently without pollution.
Technical Advantages
  • Portable design: 80% space savings and 75% weight reduction compared to traditional transformers
  • Monolithic shell design with resistance to weak acids and alkalis
  • Advanced amorphous magnetic core material for complex metallic heating
  • Wider frequency range for irregular shaped workpieces
  • Efficient heating with 8-second speed for air conditioning and refrigerator industry applications
  • Stable magnetic field output for consistent long-term heating performance
Technical Parameters
Model YYH-20AB (Three phase)
Work Power 340v-430v
Maximum Input Current 30A
Output Power 20kw
Fluctuating Frequency 50-250KHZ
Cooling Water Flow Rate 0.2Mpa, 6L/min
Water Temperature Protection Point 40°C
Product Size (Main Unit) 560x260x560mm
Product Size (Transformer) 390x260x370mm
Net Weight (Main Unit) 28kg
Net Weight (Transformer) 16kg
Application Areas
  • Brazing materials: copper, brass, tungsten steel, stainless steel, iron, aluminum, and other metal brazing
  • Glasses welding, fishing tool welding, hardware appliances welding
  • Carbide saw and saw-tooth welding, carbide blade welding
  • Jewelry and watches welding
  • Electronic industry: motor rotor hot-cooperate, electrode silver soldering and tin soldering
  • Metal implants, bulbs fight electrode
  • Band accessory soldering, golf head, pipe welding
  • Communication equipment soldering, copper coaxial cable connector soldering
Customized Automatic Magnet Wire Winding Machine for Metal & Metallurgy Coiling Process 0 Customized Automatic Magnet Wire Winding Machine for Metal & Metallurgy Coiling Process 1
