Name: 220V Electronic Salt Fog Corrosion Testing Machine Wave Style Salt Spray Aging Chamber 1 Year Warranty Salt Mist Resistance
Brand: DONGGUAN YUYANG INSTRUMENT CO., LTD
SKU: YY120-480L
Price: 2000 USD
Availability: InStock

家へ > 製品 > 環境試験室 >

220V Electronic Salt Fog Corrosion Testing Machine Wave Style Salt Spray Aging Chamber 1 Year Warranty Salt Mist Resistance

220V electronic salt fog corrosion tester

wave style salt spray aging chamber

salt mist resistance test machine

起源の場所:

中国

ブランド名:

YUYANG

証明:

モデル番号:

YY120-480L

連絡ください

引用を要求しなさい

製品詳細

試験室の大きさ (WxLxH):

1200*1000*500

機械サイズ(W×L×H)(mm):

1410*880*1280

実験室温:

NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C

飽和器の温度:

NSS.ACSS 35°C ± 1 °C / CASS 50°C ± 1 °C

湿度:

85%~98%RH

温度範囲:

± 0.5ºC

塩噴霧が減る:

1.0~2.0ml/80cm2/h

電源:

AC220V 50Hz

ハイライト:

220V electronic salt fog corrosion tester

wave style salt spray aging chamber

salt mist resistance test machine

支払いと送料の条件

最小注文数量

1セット

価格

$2000

パッケージの詳細

ベニヤ箱

受渡し時間

5～10営業日

支払条件

T/T、L/C、ウェスタンユニオン

供給の能力

月200セット

Large Capacity Salt Spray Corrosion Test Box for Various Material Testing

最良の価格を入手する

ビデオ

Titanium Alloy Salt Fog Test Chamber for Hardware and Chemical Components

最良の価格を入手する

ビデオ

Industrial Electronic Power Continuous Salt Spray Corrosion Tester 220V Saline Spray for Test Machine with 1 Year Warranty

最良の価格を入手する

ビデオ

220V Electronic Salt Fog Corrosion Testing Machine Wave Style Salt Spray Aging Chamber 1 Year Warranty Salt Mist Resistance

最良の価格を入手する

連絡ください

8613265296009

sales13@yuyangtest.com

86-769-26622869

今連絡してください

製品説明

220V Electronic Salt Fog Corrosion Testing Machine

Wave Style Salt Spray Aging Chamber with 1 Year Warranty for comprehensive salt mist resistance testing.

Product Overview

This salt spray test chamber is engineered to evaluate corrosion resistance of surface-treated materials including paints, electroplating, organic and inorganic coatings, anode processing, and anti-rust oils after anti-corrosive treatment.

Construction Materials

Laboratory chamber constructed from 5mm thick PVC sheet, capable of withstanding temperatures up to 80°C
Laboratory closure features 6mm thick high-impact acrylic sheet
Reagent supplementary bottles include water level perspective windows with hidden viewing areas for easy cleaning and durability
Saturated air barrel manufactured from SUS #304 stainless steel for optimal insulation and pressure resistance
Laboratory basket features flat indexing frame with adjustable angles, ensuring uniform mist distribution across test specimens

Compliance Standards

GB/T5170.8, GB/T2423.17, ISO-3768 3769 3770, ASTM-B117 B268, JIS-D0201, H8502, H8610, K5400 Z2371

Technical Specifications

Model	YY120-480L
Test Room Size (W×L×H)	1200 × 1000 × 500 mm
Machine Size (W×L×H)	1410 × 880 × 1280 mm
Laboratory Temperature	NSS/ACSS: 35°C ± 1°C / CASS: 50°C ± 1°C
Saturator Temperature	NSS/ACSS: 35°C ± 1°C / CASS: 50°C ± 1°C
Humidity	85% ~ 98% RH
Temperature Range	± 0.5°C
Salt Spray Settling Rate	1.0 ~ 2.0 ml/80cm²/h
Power Supply	AC220V 50HZ
